Custom Soft Enamel Souvenir Fridge Metal Magnet With Printing Logo 3D Custom Souvenir Gift

Custom Soft Enamel Souvenir Fridge Metal Magnet

Description :

Interactive kinetic storytelling in the palm. A miniature die-cast motif (such as an iconic alpine diesel locomotive) slides along an integrated mechanical track with 0.18 mm running clearance. Hand-guided motion across scenic mountain landmarks creates a playful sensory experience that keeps tourist retail displays engaging.
Precision zinc metallurgy with scratch-free mounting. Die-cast from dense Zamak 3 alloy (6.6-6.7 g/cm³) with multi-level sculptural depth. Dual flush-recessed N35 sintered neodymium magnets deliver vertical holding force across kitchen surfaces without protruding or marring appliance finishes.
Rapid engineering proofs, zero-cost mold archive. Receive production-ready 3D engineering proofs within 2 to 4 working hours, physical evaluation samples in 5 to 7 working days, and your tooling stays preserved in our archive for 2 years with zero reorder mold fees.

Base Metallurgy & Density	High-pressure die-cast Zamak 3 zinc alloy (6.6-6.7 g/cm³)
Standard Dimensions	70 mm × 50 mm × 4.5 mm (2.76″ × 1.97″ × 0.177″); track travel: 38 mm (1.50″)
Minimum Order	Pilot runs start from 100 pcs; volume pricing unlocks at 300, 500, and 1,000+ units.
Production Turnaround	3D proof: 2-4 working hours \| Samples: 5-7 working days \| Mass run: 14-18 working days
Tooling Retention	2 years free archive retention (renewed automatically on reorders); $0.00 mold fee on reorders

Send your landmark concepts or vector artwork (.AI, .EPS, .PDF or .SVG) for an itemized factory quotation and a complimentary mechanical layout proof within 2 to 4 working hours.

Chat Now Message Email

Product Description:

Product Specifications & Custom Craftsmanship Overview

Specification & Benchmark	Gold Valley Direct-Factory Standard
Base Metallurgy & Density	High-Pressure Die-Cast Zamak 3 Zinc Alloy (6.6-6.7 g/cm³) Explore Custom Fridge Magnets
Mechanical Track Assembly	Precision CNC-cut internal T-slot guide; 0.18 mm running clearance; concealed mechanical end-stops
Dimensional Tolerances	Tooling cavity CNC tolerance: ±0.03 mm (±0.0012″); finished casting profile: ±0.10 mm after buffing
Standard Body Dimensions	70 mm × 50 mm (2.76″ × 1.97″); relief thickness: 4.5 mm (0.177″); slider travel length: 38 mm (1.50″)
Magnet System & Retention	Dual recessed N35 sintered NdFeB discs (11.7-12.2 kGs); Ni-Cu-Ni triple plated; 0.08 mm sub-flush pocket
Magnetic Holding Performance	Vertical shear capacity holds ≥ 8 sheets of 80g A4 paper on standard cold-rolled steel refrigerator panels
Plating & Surface Finishes	Antique bronze, black nickel, polished chrome, vibrant soft enamel; sealed under baked acrylic clear coat
Corrosion Resistance Test	48-Hour Neutral Salt Spray (NSS) to ASTM B117 without corrosion; cross-hatch adhesion to ASTM D3359 Grade 5B
Safety & Regulatory Standards	CPSC 16 CFR 1262 magnet retention (pull-off force ≥ 60 N); RoHS 2.0 10-substance limits; REACH Annex XVII

Dynamic Sliding Rail or Classic Static 3D Relief?

Both styles start from high-precision steel tooling and dense Zamak alloy castings. The engineering difference lies in whether your souvenir tells a moving story through mechanical kinetic action or focuses purely on classical architectural monumentality.

• Dynamic Sliding Rail (Kinetic Interaction)

Best for: Mountain railways, scenic transit landmarks, alpine heritage sites, national parks, and cultural programs where trains, trams, cable cars, or vehicles interact with scenic terrain.

Tactile Heft & Feel: Dense 6.7 g/cm³ Zamak zinc casting feels balanced in hand. Pushing the miniature red diesel locomotive across the railway curve provides smooth, tactile feedback with zero binding.
Visual Depth & Storytelling: Multi-layered stepped relief creates true foreground-to-background perspective. The foreground train travels along realistic track rails beneath cherry blossom boughs and mountain clouds, drawing immediate attention on crowded souvenir retail racks.
Commercial Balance: Involves two separate tooling dies and dedicated hand assembly. Delivers a 2x to 3x retail markup in museum gift shops and premium airport duty-free stores compared to flat magnets.

• Static 3D Cast Relief (Architectural Monolithic)

Best for: Historical monuments, cathedral facades, corporate anniversary buildings, and commemorative milestones requiring single-piece sculptural dignity.

Tactile Heft & Feel: Cast as one monolithic alloy plate with deeper undercuts and pronounced 3D high-relief peaks up to 5.0 mm. Feels substantial and unbreakable.
Visual Depth & Storytelling: Preserves intricate facade filigree, masonry textures, and historic inscription plaques across a single unified metal surface without moving joints.
Commercial Balance: Streamlined single-cavity production and automated electroplating reduce assembly labor. For large-scale promotional editions requiring unified sculptural geometry, review our Explore 3D Cast Metal Fridge Magnets.

💡 Practical Craft Selection Tip: 💡 Factory Sourcing Rule of Thumb: When your regional landmark features motion—such as heritage trains entering alpine stations, gondolas traversing rivers, or opening temple gates—sliding rail construction commands higher souvenir price thresholds. For solemn cathedrals or historical statuary, stick to monolithic 3D relief castings.

Kinetic Engineering & Hardware Integration Options

An interactive magnet must survive thousands of playful slides without jamming, derailing, or scratching painted surfaces. We engineer each kinetic component with dedicated mechanical retention and protective backing features.

Precision T-Track Guide

Standard for linear travel

The slider stem features a precision T-profile that anchors into a recessed channel. Smooth 0.18 mm operating clearance prevents lateral wobbling while maintaining effortless gliding motion across the landscape.

Dual Recessed N35 Magnets

Heavy metal pieces

Twin sintered neodymium discs press-fitted into dedicated sub-flush cavities with cross-pattern air relief channels. Modified epoxy bonding resists up to 60 N pull-out force to prevent detachment.

Concealed End-Stop Bumpers

High-traffic retail durability

Tooling incorporates hidden mechanical travel stops at both ends of the sliding track. Even vigorous thumb pushes will not pop the miniature moving figure out of its guided channel.

Anti-Scratch Felt Backing

High-gloss appliance protection

Die-cut dense micro-fiber felt covers the rear perimeter. Prevents raw metal edges or friction points from making direct contact with high-gloss automotive and home appliance paintwork.

Multi-Tier Architectural Relief

Scenic landscape perspective

The base casting incorporates stepped elevation planes. Distant sunrise peaks, rolling sea of clouds, historic wooden station architecture, and foreground cherry blossoms separate cleanly into distinct visual zones.

Interchangeable Slider Motifs

Seasonal or multi-character batches

A unified base track accommodates multiple sliding cast figures—such as vintage diesel locomotives, classic steam engines, electric tram cars, or cable cars—allowing tourist destinations to run multi-motif collections on one base mold.

Special Finishes & Advanced Visual Styling

Surface finishing defines how vintage architecture, natural foliage, and mechanical vehicles reflect ambient light. These four surface treatments bring heritage railways and natural wonders to life.

Process / Effect	Technical Formulation & Appearance	Best Applications
Antique Bronze & Gunmetal Relief Buffing	Chemical surface darkening followed by hand cloth-wheel relieffing. Shadow tones linger in wooden station planks and track ties while raised metal highlights gleam with rich metallic warmth.	Mountain railway heritage sites, national parks, transit museums
High-Luster Gold & Bright Chrome Plating	Acid copper leveling under bright nickel, layered with genuine gold or mirror chrome. Multi-layer plating creates striking contrast between metallic locomotive edges and natural scenery.	Commemorative transit jubilees, premium railway anniversary editions
Recessed Soft Enamel Scenic Infill	Fluid enamel color paste manually dispensed into vibrant cherry blossom petals, blue mountain horizons, and scarlet locomotive livery, then heat-cured. High-contrast colors bring alpine nature to life.	Spring tourism festivals, national park gift shops, botanical gardens
Luminescent Glow-in-the-Dark Cloud Accents	Strontium aluminate photoluminescent pigment blended into mountain mist and cloud fills. Emits a soft turquoise nightglow after light exposure, turning historic day scenes into romantic nightscapes.	Night tourism destinations, observatory gift shops, evening festivals

For comprehensive electroplating bath specifications and salt spray testing protocols, review our Industrial Electroplating & Finishes Standard.

Retail Presentation & Tourist Merchandising Solutions

Retail packaging transforms a metal souvenir into an impulse gift ready for airport boutiques, museum bookstores, and tourist gift displays.

Individual Self-Sealing OPP Sleeve (Included Default)
Crystal-clear polybag with protective peel-and-seal flap. Protects plated surfaces during transit and offers a lightweight, zero-cost packaging baseline.

Custom Euro-Slot Backing Card (Retail Peg Upgrade)
350g rigid art paperboard printed in 4-color offset with a Euro-hook punch. Displays regional scenic artwork and barcode branding for instant retail hanging.

Optical Clear Acrylic Display Case (Archival Display Upgrade)
Rigid clear acrylic case fitted with a custom die-cut EVA interior tray. Keeps the metal magnet dust-free and viewable as an upright collector desk showcase.

Magnetic Book-Style Gift Box (Executive Gift Presentation)
Premium rigid card box with magnetic flip-top closure, hot-stamped gold foil logo, and custom-molded high-density foam insert. Built for official delegations.

From Concept to Creation: Direct-Factory Production & Quality Assurance

1. Split-Die 3D CNC Tooling	Engineering breaks your scenic artwork into two matching H13 steel toolings: the multi-level background base and the miniature sliding component, cut with ±0.03 mm CNC precision.
2. High-Pressure Die Casting	Zamak 3 alloy is injected into automated hot-chamber die casting machines under 88-ton clamping force, capturing sharp railway tracks, cherry blossom florets, wooden station architecture, and layered mountain cloud banks.
3. Hand De-Burring & Track Broaching	Technicians deburr part lines across multi-stage cloth wheels and verify track channel dimensions to eliminate burrs that could restrict slider travel.
4. Multi-Barrier Plating & Anti-Tarnish Bake	Castings pass through ultrasonic degreasing, copper strike, acid leveling, and antique plating, sealed under a baked acrylic protective clear coat for everyday sweat and handling protection.
5. Color Infill & Thermal Curing	Opaque or translucent enamel pastes mixed to approved Pantone standards are dispensed into blossom petals, mountain skies, and locomotive livery, then baked to a durable, chip-resistant finish.
6. Kinetic Assembly & 100% Slide Inspection	Operators align the T-track guide, press-fit twin N35 neodymium magnets into sub-flush pockets with modified epoxy, and test each piece for fluid, snag-free sliding motion.

Factory Assurance: Tooling tolerances, slide clearance, and magnetic pull standards are certified under the direction of Tooling & Quality Director Lin Jianhua (Gold Valley Dongguan Works). The 3,000 m² plant operates under ISO 9001:2015 certification and annual Sedex SMETA 4-Pillar ethical manufacturing audits.

[RFQ] Sourcing Spec Sheet (Copy-Paste for Your RFQ)

Paste the baseline below straight into your request for quotation, or submit directly to our Direct Engineering Desk for rapid 2-4h factory pricing:

• Base Metallurgy: High-Pressure Die-Cast Zamak 3 Zinc Alloy (density 6.6-6.7 g/cm³)

• Mechanical Sliding Track: Integrated internal T-slot guide; 0.18 mm running clearance; dual concealed travel stops; 38 mm standard travel length

• Overall Dimensions: Base plate 70 mm × 50 mm (2.76″ × 1.97″); relief thickness 4.5 mm (0.177″); slider motif 22 mm × 15 mm

• Magnet System: Dual recessed sintered NdFeB N35 discs (11.7-12.2 kGs); Ni-Cu-Ni triple plating; 0.08 mm sub-flush pocket with air vent; pull-off force ≥ 60 N

• Surface Finishing: Antique bronze / black nickel / soft enamel with manual buffing; baked acrylic protective clear coat; 48h ASTM B117 salt spray passed

• Quality Benchmark: ISO 2859-1 AQL 1.5 Major / 4.0 Minor; 100% piece-by-piece tactile sliding motion verification; ASTM D3359 Grade 5B adhesion

(Engineered to Gold Valley Factory Tolerances — Dongguan Facility)

Custom Sliding Rail Fridge Magnets: Ordering & Production FAQ

How does the sliding mechanism work, and will the moving piece fall off over time?

A: The moving figure is anchored by an integrated T-shaped stem guided within an internal machined channel with 0.18 mm running clearance. Tooling incorporates concealed mechanical end-stops at both travel limits. The slider cannot be pulled outward or pushed past the edges during normal handling, maintaining reliable linear gliding motion over years of use.

Will the metal back or magnets scratch high-gloss refrigerator surfaces?

A: No. We design the magnet pockets to sit 0.08 mm deeper than the magnet thickness, ensuring the metallic magnet disc stays sub-flush rather than grinding against refrigerator doors. Furthermore, we fit high-density die-cut microfiber felt pads across the rear base, completely cushioning metal-to-appliance contact.

How strong is the magnetic hold, and will the magnet slide down under its own weight?

A: Each piece uses two sintered NdFeB N35 rare-earth magnets with Ni-Cu-Ni triple anti-corrosion plating. Unlike weak flexible rubber magnets, this dual neodymium setup generates sufficient vertical holding force to support the heavy 65g metal casting plus up to 8 sheets of A4 paper on standard cold-rolled steel refrigerator panels without slipping.

What file formats are required, and how fast can you provide production drawings?

A: We accept vector artwork in .AI, .EPS, .PDF, or high-resolution .PNG/.PSD. If you only have regional landmark photographs or scenic sketches, our engineering department will separate the background and foreground sliding layers and supply a 3D mechanical layout proof within 2 to 4 working hours at no charge. Submit files through our Direct Engineering RFQ Desk.

What is the minimum order quantity and standard production turnaround?

A: Pilot runs start from 100 pieces per design, allowing scenic spots to test retail velocity. Cost efficiencies scale significantly at 300, 500, and 1,000+ units where initial two-piece tooling costs are fully amortized. Tooling and sampling require 5 to 7 working days; mass manufacturing takes 14 to 18 working days. Rush tooling turnaround within 72 hours is available for fixed festival dates.

What factory credentials and product safety certifications apply to this magnet?

A: Our 3,000 m² Dongguan facility operates under ISO 9001:2015 quality certification and annual Sedex SMETA 4-Pillar audits. For authorized souvenir collections, we maintain Disney FAMA (FAC-086164) and NBCUniversal (L-8360-DT-004) authorizations. The product complies with CPSC 16 CFR 1262 and ASTM F963-23 magnet retention safety standards, while the plating stack meets RoHS 2.0 10-substance limits and REACH Annex XVII heavy metal limits.
